Design standards compatibility: Design standards are not compatible with local specifications? Our advantage: team engineers and others are familiar with local specifications and design.
Installation Support: Worry about the lack of installation guidance? Our advantage: provide comprehensive installation drawings, etc.
Specifications: steel grade, design load, seismic grade, wind grade, fire rating requirements, etc.
Main Steel: Q355B / Q235B High Strength Structural Steel → Advantage: Ensure structural safety and stability in accordance with international standards.
Surface treatment: hot dip galvanizing / antirust paint (specify thickness and standard) → Advantage: excellent anti-corrosion properties and rust prevention, prolonging the service life of the building and reducing maintenance costs.
| Structure | Material | Details |
|---|---|---|
| Main Structure | Frame Columns and Beams | Q235B/Q355B Equivalent to S355JR, ASTM A572 Grade 50 |
| End Wall Column | Q235B/Q355B | |
| H-beam welding（columns and beams） | Automatic Submerged Arc Welding | |
| Rust Removal | Shot Blasting | |
| Surface Processing | Alkyd Paint/Epoxy Zinc Rich/Galvanized | |
| High-Strength Bolt | Grade 10.9/8.8 | |
| Common Bolt | Grade 4.8 | |
| Secondary Structure | Flange Brace | Angle Steel |
| Horizontal Support | Angle/Round Steel | |
| Vertical Support | Angle/Round Steel | |
| Tie Rod | Angle/Round Steel | |
| Tie Bars | Round Steel/Casing/Shaped Steel | |
| Purlin | Galvanized Z-beam/C-beam | |
| Enclosure system | Roofing Materials (Roofing system) | 360°Locking Seam System / Locking Screw System / Composite Panel Roofing / Rockwool Maintenance System |
| Daylighting Band (Roofing system) | FRP Plate | |
| Gutter (inside/outside) (Roofing system) | Stainless Steel/Colored Steel Plate | |
| Rain Pipe (Roofing system) | PVC Pipe/Colour Steel Rainwater Pipe | |
| Wall Materials (Wall System) | Locking Screw System / Composite Panel Wall / Rockwool Maintenance System | |
| Accessories (Wall System) | Sealant, Self-tapping Self-drilling Screws, etc. | |
| Edge Flashing (Wall System) | Color Plate/Stainless Steel | |
| Others | Ventilator | Powered/Unpowered Axial Flow Ventilators (Customizable) |
| Ventilation tower | Finished Product (Customizable) | |
| Door | Electric Rolling Door/Sliding Door/Fireproof door/Industrial Sliding Doors / Industrial Lift-Up Doors / Industrial High-Speed Stacking Doors / Aluminum Alloy Doors / Wooden Doors / Steel Fire-Rated Security Doors (Customizable) | |
| Window | Aluminum Alloy/plastic Steel Window/Fireproof Window (Customizable) |
