| Structure Part | Specification | |
| Project | Steel Structure Building | |
| Size | According to Customer Need | |
| Main Steel Structure Frame | ||
| Column | Q235B, Q355B Welded H Section Steel | |
| Beam | Q235B, Q355B Welded H Section Steel | |
| Secondary Steel Structure Frame | ||
| Purlin / Brace | Q235B C and Z Type Steel / Round Bar | |
| Tie Tube | Q235B Circular Steel Pipe | |
| Support System | Angle Steel, Round Bar or Steel Pipe | |
| Roof and Wall System | ||
| Cladding | Steel Sheet or Sandwich Panel (EPS, PU, Glass Wool, Rock Wool) | |
| Door / Window | Sliding/Rolling Doors, Aluminium Alloy/PVC Windows | |
Steel structure building is a popular building system where main load-bearing members (columns, beams, foundations) are made of steel. Roofs and walls utilize materials like sandwich panels, steel sheets, wire mesh, or ALC boards.
Connection Method: Columns connect to foundations via pre-embedded anchor bolts. Beams and columns use high-intensity bolts.
Construction Advantages: • Custom design for any environment • Long life span (50+ years) • Quick & easy installation • Economic & eco-friendly • Seismic & wind resistance.
